Sliding Doors & Windows

Our range of Sliding Systems offers an excellent solution for maximizing space and seamlessly connecting indoor and outdoor areas. By incorporating our aluminum sliding doors and sliding folding doors, you can create expansive glazed areas that invite ample natural light into any room. These innovative systems effectively minimize barriers, allowing for a smooth transition between the interior and exterior spaces.

ALUMIL M14000

Description

M14000 is a complete non-thermal-break system for sliding doors and windows, with a large variety of profiles. Among other features, a special design can be achieved thanks to 90o cuttings and by minimizing the visible aluminium frame of the interlocking profile.

Advantages

  • Stainless steel rails offer smooth and easy scrolling of the sashes
  • Suitable for any typology of sliding doors and windows
  • Possibility of sliding shutters or/and sliding flyscreens
  • In-Wall Sliding concealed vents
  • Multipoint locking hardware for a higher security level
  • Interlocking face width profile of only 27 mm for maximum visibility for double sash

Generic

WINDOW TYPES Sliding
THERMAL INSULATION Non-Thermal
EXTERIOR SHAPES Curved, Flat

Characteristics

FRAME DEPTH 92 mm
SASH WIDTH 38 mm
MINIMUM VISIBLE ALUMINIUM FACE HEIGHT 111.8 mm
MAXIMUM GLAZING THICKNESS 26 mm
SEALING METHOD Continuous perimetrical tri fin in two levels brush
TYPES OF TYPOLOGY Horizontal sliding, Meeting stile, Pocket sliding, Multiple horizontal sliding
MINIMUM VISIBLE ALUMINIUM FACE WIDTH AT THE CENTRAL VERTICAL COLUMN (INTERLOCKING PROFILE) 27 mm
GLAZING TYPE Single, Double
MECHANISM Perimetrical locking mechanism
SASH WEIGHT 130 kg (Max.)

Typologies

Sections
